Deye Three Phase Energy Meter three-phase smart energy meter for DIN rail mounting. It measures voltages, currents, active and reactive power, frequency, and bidirectional energy, with RS485 communication via the MODBUS-RTU protocol.
The Deye Three Phase Energy Meter is a three-phase smart energy meter designed for a standard 35 mm DIN rail. It combines measurement and communication functions, allowing the monitoring of voltages, currents, active and reactive power, frequency, as well as positive and negative (four-quadrant) energy. The modular, compact design facilitates installation and the creation of measurement networks in photovoltaic systems and energy storage.
| Reference voltage | 3×230 / 400 V |
| Current specification | 100 A / 40 mA or 250 A / 50 mA (with transformer) |
| Meter constant | 400 imp/kWh |
| Accuracy class (active power) | class 1 |
| Communication interface | RS485 (MODBUS-RTU) |
| Installation | 35 mm DIN rail |
| Operating temperature range | -25 to +70°C |
| Relative humidity (annual average) | <75% non-condensing |
| Atmospheric pressure | 63.0–106.0 kPa (altitude up to 4 km) |
| Standards | IEC 61010-1:2010, IEC 61326-1:2020 |
Deye Three Phase Energy Meter — 3-phase DIN rail energy meter — B2B wholesale prices for installers and contractors. Check availability and terms of cooperation: contact us.
B2B
Individual terms, account manager.
