Three-phase grid-tied inverter Huawei 3-Phase Inverter 115 kW AFCI Huawei SUN2000-115KTL M2 with 115 kW output, 10 MPPT trackers, and up to 98.8% max efficiency. Features smart air cooling, designed for large commercial installations and PV farms.
Huawei 3-Phase Inverter 115 kW AFCI Huawei SUN2000-115KTL M2 is a three-phase grid-tied inverter with a rated output of 115 kW, designed for large commercial, industrial, and utility-scale PV farms. Up to 10 MPPT trackers, Smart String Level Disconnector, and Smart I-V Curve diagnosis provide full control over the installation. A maximum efficiency of up to 98.8%, smart air cooling, and an IP66 protection rating guarantee high yields and reliable outdoor operation.
| Rated AC power | 115,000 W |
| Max AC apparent power | 125,000 VA |
| Max DC input voltage | 1100 V |
| MPPT voltage range | 200 V ~ 1000 V |
| Startup voltage | 200 V |
| Number of MPPT trackers | 10 |
| Max number of inputs per tracker | 2 |
| Max current per MPPT | 30 A |
| Output voltage | 400 / 480 V, 3W+(N)+PE |
| Max efficiency | 98.8% @480V / 98.6% @400V |
| European efficiency | 98.6% @480V / 98.4% @400V |
| Cooling | Smart Air Cooling |
| Protection rating | IP66 |
| Operating temperature range | -25°C ~ +60°C |
| Dimensions (W×H×D) | 1035 × 700 × 365 mm |
| Weight (with mounting plate) | ≤93 kg |
Huawei 115 kW 3-phase Inverter AFCI Huawei SUN2000-115KTL M2 — 115 kW 3-phase grid-tied in — B2B wholesale prices for installers and contractors. Check availability and terms of cooperation: contact us.
