Sigen Gateway C&I 600 kW (C600-B) - ATS connection switchgear for HYB series is a three-phase ATS switchgear with a capacity of 600 kW for the HYB series, supporting up to 30 inverter ports. It provides uninterrupted 0 ms switching and 350 ms anti-reverse power protection.
Sigen Gateway C&I 600 kW (C600-B) is a three-phase ATS switchgear with a nominal power of 600 kW, designed for HYB series inverters in large commercial and industrial installations. It supports up to 30 inverter ports and multiple SigenStor connections in a microgrid.
| Grid connection type | Three-phase |
| Nominal AC voltage | 380~400 V |
| Nominal AC current | 912 A |
| Nominal AC power | 600 kW |
| AC frequency | 50 / 60 Hz |
| Backup switchover time | 0 ms |
| Overvoltage category | III |
| Number of inverter ports | 30 |
| Max. AC input current | 45.6 A |
| Cooling | Smart air cooling |
| Protection rating | IP20 |
| Communication | Fast Ethernet, RS485, dry contact |
| Mounting | Freestanding (floor-mounted) |
| Weight | 1100 kg |
| Operating temperature range | -30~55°C |
Sigen Gateway C&I 600 kW (C600-B) - ATS connection box for HYB series — ATS connection box — B2B wholesale prices for installers and contractors. Check availability and terms of cooperation: contact us.
